2u rackmount server case hotswap 9 trays Rackmount server chassis

Module

R248-9  Industrial Case

Product Feature:

R248-9  is one kind of standard 19" processing industry Case with the height of 2U by applying high-quality Ma Steel flowers-free zinc plating. Featuring novel structural design, it is solid, compact and reasonable in design and easy for installation and operation. Meanwhile, it contains nine  3.5-inch hard disks rive,Meanwhile, the company’s products are widely applied in different sectors including industrial automation, communication, electricity, network safety, intelligent transportation, video surveillance, medical care, military industry/aerospace industry, self-service terminal, date storage, digital signage, car-mounted computer and 3C application etc.

Technical Parameters:

Dimensions

482(W)*480(D)*89 mm(H)

Main Board

12"* 9.6"(305 * 245MM)

Hard Disk

nine 3.5-inch Hard Disk

CD-ROM

No

Power

2U power supply

Fan

Three 8025 Fans;

Expansion Slot

Seven Half High and Straight Slots

Panel Setting

Two USB2.0; One Power Switch; One Restart Switch; One Power Indicator; One HD Indicator

Case Material

SGCC

Material Thickness

1.2MM

Delivery time

1 Week for sample ,2 Weeks for mass goods

Payment Terms

30%TT Prepay 70%TT before shipment
